400 ET3 High Performance IGBT Welding Rectifier For Outdoor Fabrication
Product Details:
400 ET3 High Performance IGBT Welding Rectifier For Outdoor Fabrication Price And Quantity
- 50000 INR/Unit
- 10 Unit
400 ET3 High Performance IGBT Welding Rectifier For Outdoor Fabrication Trade Information
- 500 Unit Per Month
- 10 Days
Product Description
Specification
| Technical Specification | Units | 400 ET3 |
| INPUT | ||
| Rated input voltage | Volts | 415, 20 % |
| Phase/Freq. | No./Hz | 3ph/50-60 |
| Max. input KVA@60% Duty cycle | KVA/KW | 17.60/16.70 |
| OUTPUT | ||
| Rated current range | Amps | 20-400 |
| Rated output voltage | Volts | 36 (MMAW) /26 (Scratch TIG) |
| Voltage reduction device (VRD) |
| <13 V DC |
| Welding current ( 40 C ) |
|
|
| @60% Duty cycle | Amps | 400 |
| @100%duty cycle | Amps | 310 |
| GENERAL | ||
| Conformance to international standard |
| All machines are manufactured as per std. IEC 60974-1:2000/GB 15579.1:2004 |
| Power control method |
| IGBT inverter controlled |
| Digit display |
| 4 Digit, 7 segment LED display |
| Hot start & Arc force |
| Adjustable from front panel |
| Ingress protection | Class | IP 23 |
| Insulation | Class | H |
| Cooling | type | Forced air cooling |
| Power factor |
| >0.9 |
| Operating temperature | C | -10 to 50 |
| Air carbon arc gouging | mm |
|
| Dimension ( LxBxH) | mm | 327x 560x 602 |
| Weight | kg | 36 kg |
| Ordering information |
| Model no. |
| Power source with remote socket |
| YT-400ET3DJR |
